This Intellian® i5 satellite system (2018) is owned by a private person. The antenna is suitable for NL TV reception via the Astra 23,5 satellite (= Canal Digitaal / TV Vlaanderen) and German channels via the Astra 19,2 satellite. Antenna system has been tested by us and provided with the latest updates. The antenna is in fine condition.

Power and efficiency. - These concepts make the Intellian® i5 the most popular 61 cm (24 inch) automatic satellite TV solution for pleasure boats, fishing boats, work boats and commercial vessels from 12 meters (35 ft) to 20 meters (60 ft) in length.

Intellian® i5 highlights

• Automatic satellite selection function via remote control
• Compatible with leading satellite TV providers worldwide
• The rotation speed of 50° per second allows for signal tracking at both high speeds and in rough seas
• An extended elevation range of 0° to 90° allows you to travel far to the North or South
• Built-in GPS system allows for quick finding of the desired signal
• Simplicity of design, no external compass or speed sensors required
• Built-in HD module for Ku-band HD TV reception

Travel further than ever

You never have to compromise when it comes to reception or quality. The Intellian® i5 offers the highest signal strength attainable with a 45 cm (17.7") dish antenna, significantly expanding coverage area. Expand your horizion with the Intellian® i4.

Astra 1	Astra 2a	Hispasat
HotBird		HotBird widebeam	Thor II

Long distance sailing

The i5 from Intellian® is available in 2 variants: the "regular" i5 or the i5P with Auto Skew function.

For example, the i5P model is ideal for ships sailing between different locations within a global region, where the polarization angle of the satellite signal is subject to change. For example: Europe, South America, Asia-Pacific.

All Intellian "P" models are equipped with an integrated Auto Skew angle adjustment, eliminating the need to adjust -manually- the skew angle of the LNB.

Automatic satellite switching

DISH Network (U.S.) and Bell TV (Canada) users will benefit from using the Intellian MIM (Multi-Satellite Interface Module). The Intellian MIM is needed to enable automatic switching between satellites, which also allows water sports users who want to switch channels to automatically switch to the correct satellite, just like satellite TV at home.

Intellian® i5 features

Fully automatic system

• Automatic satellite search and identification function
• The 2-axis stabilization ensures fast finding of the correct satellite/signal strength

High performance satellite dish

• The parabolic dish has a diameter of 61cm (24inch) and is suitable for reception of Ku-band satellite signals
• Both circular and linear polarization, depending on region and selected LNB
• Built-in HD module for Ku-band HD TV reception

Intellian's patented Quick & Quiet℠ Technology (IQ²)

• With the patented IQ² Technology, quick tuning to the desired satellite is possible and this technology ensures solid signal quality while watching your favorite TV programs. Even while sailing!
• The Wide Range Search (WRS) algorithm allows for quickly finding the best signal strength available -wherever
• Dynamic Beam Tilting (DBT) technology uses intelligent, real-time beam analysis to provide a ​​superior signal quality, while this technology eliminates intrusive background noise -that one may experience with conventional satellite dishes

Control unit

• Intuitive control with digital information display on the ACU
• Wireless automatic updates and diagnostics via Aptus PC and Aptus Mobile
• DC Out port for easy power supply to the Intellian MIM or Shaw Decoder Module

Multiple connections possible

Multiple satellite receivers and/or televisions can be connected to the Intellian i5 using a multi-switch or the Intellian MIM system (Multi-Satellite Interface Module). Through the MIM, a master receiver can be selected to receive the desired satellite.

In North America, when using Dish Network or Bell TV, an MIM is required; this allows automatic satellite switching through your remote control, just like in your home.

Built-in GPS and NMEA 0183 Interface

• The Intellian® i4 features a built-in GPS antenna for quick alignment to the correct satellite / best signal strength.
• The vessel's GPS system can also be connected via the NMEA 0183 port on the ACU's rear panel.

Compact size

The Intellian® i5 has an all around diameter of 61cm (24 inches) and weighs 17.3 kg (38 pounds).

Delivery contents

• Antenna & Radome 61cm (24 inch) Reflector & LNB
• ACU (Antenna Control Unit)
• PC Controller Program (software CD included)
• Installation and Operation Manual
• Installation Template
• Quick Installation Guide

Installation Kit

• ACU Table Mounting Bracket × 2EA
• 15 m (49 ft) × 1EA Antenna-ACU RG6 coaxial cable
• 3 m (10 ft) × 1EA ACU-IRD RG6 coaxial cable
• 10 m (33 ft) × 1EA DC power cable
• 1.8 m (6 ft) × 1EA PC seriële kabel
• Connectors & schroeven

Comparison table Intellian® i9, i6, i4 and i3 model

	SatFlower i9	SatFlower i6P	SatFlower i4	SatFlower i3
Diameter antenna	85cm	60cm	45cm	37cm
Dimensions	122 x 113cm	70 x 72cm	50 x 53cm	43 x 44cm
Weight	56.2kg	18kg	14kg	9kg
Minimum EIRP	44dBw	47dBw	49dBw	50dBw
Suitable for	North America, Europe, Central America, South America, Asia, Africa, Middle East, Oceania	Europe, Central America, South America, Asia, Africa, Middle East, Oceania	North America, Europe, Central America, South America, Asia, Africa, Middle East, Oceania	North America, Europe, Central America, South America, Asia, Africa, Middle East, Oceania
Antenna Control Unit	Yes	Yes	Yes	Yes
Automatic SKEW	Yes	Yes	No	No
HDTV compatible	Yes	Yes	Yes	Yes
GPS integrated	Yes	Yes	No	No
GPS interface	Yes	Yes	Yes	Yes
